Comb for the Leatherman FREE Series

Name: Comb for the Leatherman FREE Series
Brand: Shapeways
Price: 17.0 USD
Availability: InStock

$17.00

Shipping calculated at checkout. This item typically ships in 1-2 Weeks

I want to replace the

Serrated Blade or Scissors

Main Blade or Saw

FREE T2 or T4 Short Version

[{"id":42474738122921,"title":"Serrated Blade or Scissors","option1":"Serrated Blade or Scissors","option2":null,"option3":null,"sku":null,"requires_shipping":true,"taxable":false,"featured_image":{"id":36715653529769,"product_id":7562990354601,"position":1,"created_at":"2022-08-13T17:52:18-05:00","updated_at":"2022-08-13T17:52:18-05:00","alt":null,"width":3840,"height":2160,"src":"https:\/\/cdn.shopify.com\/s\/files\/1\/0560\/2977\/3993\/products\/Comb_Serrated-Scissors_PA11.png?v=1660431138","variant_ids":[42474738122921]},"available":true,"name":"Comb for the Leatherman FREE Series - Serrated Blade or Scissors","public_title":"Serrated Blade or Scissors","options":["Serrated Blade or Scissors"],"price":1700,"weight":0,"compare_at_price":null,"inventory_management":null,"barcode":null,"featured_media":{"alt":null,"id":29076044578985,"position":1,"preview_image":{"aspect_ratio":1.778,"height":2160,"width":3840,"src":"https:\/\/cdn.shopify.com\/s\/files\/1\/0560\/2977\/3993\/products\/Comb_Serrated-Scissors_PA11.png?v=1660431138"}},"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":42474738221225,"title":"Main Blade or Saw","option1":"Main Blade or Saw","option2":null,"option3":null,"sku":null,"requires_shipping":true,"taxable":false,"featured_image":{"id":36715655069865,"product_id":7562990354601,"position":3,"created_at":"2022-08-13T17:52:48-05:00","updated_at":"2022-08-13T17:52:48-05:00","alt":null,"width":3840,"height":2160,"src":"https:\/\/cdn.shopify.com\/s\/files\/1\/0560\/2977\/3993\/products\/Comb_Saw-Main_PA11.png?v=1660431168","variant_ids":[42474738221225]},"available":true,"name":"Comb for the Leatherman FREE Series - Main Blade or Saw","public_title":"Main Blade or Saw","options":["Main Blade or Saw"],"price":1700,"weight":0,"compare_at_price":null,"inventory_management":null,"barcode":null,"featured_media":{"alt":null,"id":29076046119081,"position":3,"preview_image":{"aspect_ratio":1.778,"height":2160,"width":3840,"src":"https:\/\/cdn.shopify.com\/s\/files\/1\/0560\/2977\/3993\/products\/Comb_Saw-Main_PA11.png?v=1660431168"}},"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":42974495146153,"title":"FREE T2 or T4 Short Version","option1":"FREE T2 or T4 Short Version","option2":null,"option3":null,"sku":"","requires_shipping":true,"taxable":false,"featured_image":{"id":37726711447721,"product_id":7562990354601,"position":5,"created_at":"2023-03-15T21:27:17-05:00","updated_at":"2023-03-15T21:27:17-05:00","alt":null,"width":3840,"height":2160,"src":"https:\/\/cdn.shopify.com\/s\/files\/1\/0560\/2977\/3993\/products\/Comb_FREET2.png?v=1678933637","variant_ids":[42974495146153]},"available":false,"name":"Comb for the Leatherman FREE Series - FREE T2 or T4 Short Version","public_title":"FREE T2 or T4 Short Version","options":["FREE T2 or T4 Short Version"],"price":1700,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":"","featured_media":{"alt":null,"id":30111209521321,"position":5,"preview_image":{"aspect_ratio":1.778,"height":2160,"width":3840,"src":"https:\/\/cdn.shopify.com\/s\/files\/1\/0560\/2977\/3993\/products\/Comb_FREET2.png?v=1678933637"}},"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}]

This modification adds a plastic hair comb to your Leatherman FREE P4, P2, Mr. Crunch, or T2 or T4

Features:

An every day carry comb you can keep on your multitool.
Built-in thumb-tab for easy deployment.
Strong and highly flexible Nylon 11 material.
0.1" thick. The same thickness as the Main Blade, Serrated Blade or Scissors.
Hole for an optional retaining magnet. (P series only)
White material can be dyed using alcohol based inks.

#SerratedBladeorScissors

Your current selection: Replaces the Serrated blade or Scissors

#MainBladeorSaw

Your current selection: Replaces the Main Blade or Saw
Saw replacement:
The saw on the FREE P4 is thinner than the comb , but the comb can be installed if you remove some of the thin washers that are between the thin implements on your P4.

#FREET2orT4ShortVersion

T2 & T4 version coming soon...(In prototyping)
Your current selection: Short Version, Replaces the Main Blade on the T2 or T4
This part doesn't have room for the magnet, but is retained by the cam on the tool.

Optional Retaining Magnet:

Because the material is non-magnetic: A hole has been designed in to add an optional retaining magnet.

Due to the way Shapeways works: The magnet needs to be purchased separately.

The recommended magnet is 1/8" Diameter x 1/10" Thick neodymium magnet. The following magnet is compatible:

K&J Magnetics P/N: D2H1

A small bit of super-glue may be used to hold the magnet.

Installation:

The tool must be taken apart to install this modification. Any warranty concerns are entirely up to the user.

You will need two Torx T9 bits to remove the screws holding the tool together.
The screws need to be loosened by holding one side with a bit, and turning the other side.
The screws are secured using thread-locking compound, and heat may be required to loosen the compound.
Care should be taken to open the tool on a clean surface.
Keep the thick washer between the scales and the comb.
The tightness of the tool will depend on the amount of torque you apply during reassembly.

FREE P4 stack-up:

FREE P2 stack-up:

What am I getting / not getting?:

This list will update depending on the options selected

Included:

#SerratedBladeorScissors

● One 3D Printed comb, meant to replace the Serrated blade or Scissors

#MainBladeorSaw

● One 3D Printed comb, meant to replace the Main blade or Saw*

#All

Not included:

● Leatherman Tool

● Magnet

How Shapeways fulfillment Works:

Many items on this website are manufactured by Shapeways.com

The parts are professionally 3D printed, and then drop shipped to your address.

I cannot customize, alter or process any returns after your order has been placed. All sales are final.

ZapWizard is the part designer. I receive a fixed portion of the total order.

Upon order you will receive a confirmation of the order, and a notification upon shipment. If you need more details on the state of an item please send me a message with the order number, or place your order directly on my Shapeways.com store.

All items in the US are shipped using UPS Mail Innovations. This means your shipment will be transferred your local carrier for final delivery. If you require faster shipping or international shipping: Please order directly from the Shapeways.com marketplace.

Shipping costs and any other related fees related to Shapeways are controlled by Shapeways.com. For more information please see the Shapeways.com page on shipping time and costs.

Shapeways.com provides a 10-day warranty for manufacturing defects. Please contact me as soon as possible if you have any defects such as a warped metal part, or heavily filled area. Please include your order number and a photo of the defective part.

About the material:
Made from flexible yet strong Nylon 11 plastic. The part is created using 3D printed laser sintered plastic. The result is a solid plastic component.

Custom Colors:
If you want a color not available above: You can dye the parts using any alcohol based permanent marker. The surface is slightly porous and will hold color well. They may also be dyed using any fabric dye compatible with Nylon (Polyamide).

Material specs and MDS sheets located here.
